Load ODIM_H5 Volume data from German Weather Service#

In this example, we obtain and read the last 2 hours of available volumetric radar data from German Weather Service available at opendata.dwd.de. Finally we do some plotting.

This retrieves 24 timesteps of the 10 sweeps (moments DBZH and VRADH) of the DWD volume scan of a distinct radar. This amounts to 480 data files which are combined into one volumetric Cf/Radial2 like xarray powered structure.

Exports to single file Odim_H5 and Cf/Radial2 format are shown at the end of this tutorial.

Warning

The following code is based on xarray and xradar. It claims multiple data files and presents them in a DataTree.

import glob
import os
import shutil
import warnings
from html.parser import HTMLParser

import cartopy.crs as ccrs
import certifi
import matplotlib.pyplot as plt
import numpy as np
import urllib3
import xarray as xr
import xradar as xd
from IPython.display import display

warnings.filterwarnings("ignore")

class DWDHTMLParser(HTMLParser):
    def handle_starttag(self, tag, attrs):
        if tag != "a":
            return
        self.links.append(attrs[0][1])


parser = DWDHTMLParser()

Download data from opendata.dwd.de #

radar = "ESS"
DBZH = "sweep_vol_z"
VRADH = "sweep_vol_v"

opendata_url1 = f"https://opendata.dwd.de/weather/radar/sites/{DBZH}/{radar.lower()}/hdf5/filter_polarimetric/"

http = urllib3.PoolManager(cert_reqs="CERT_REQUIRED", ca_certs=certifi.where())
response = http.request("GET", opendata_url1).data.decode("utf-8")

parser.links = []
parser.feed(response)
filelist1 = parser.links[1:]

filelist1.sort(key=lambda x: x.split("-")[2])
filelist1.reverse()

opendata_url2 = f"https://opendata.dwd.de/weather/radar/sites/{VRADH}/{radar.lower()}/hdf5/filter_polarimetric/"

http = urllib3.PoolManager(cert_reqs="CERT_REQUIRED", ca_certs=certifi.where())
response = http.request("GET", opendata_url2).data.decode("utf-8")

parser.links = []
parser.feed(response)
filelist2 = parser.links[1:]

filelist2.sort(key=lambda x: x.split("-")[2])
filelist2.reverse()

Clean up local folder#

flist = glob.glob("ras07*")
for f in flist:
    os.remove(f)

Download latest 24 volumes to current directory#

for f in filelist1[: 10 * 25]:
    with http.request(
        "GET", os.path.join(opendata_url1, f), preload_content=False
    ) as r, open(f, "wb") as out:
        shutil.copyfileobj(r, out)

for f in filelist2[: 10 * 25]:
    with http.request(
        "GET", os.path.join(opendata_url2, f), preload_content=False
    ) as r, open(f, "wb") as out:
        shutil.copyfileobj(r, out)

volume_reflectivity = glob.glob("ras07*_dbzh_*")
volume_velocity = glob.glob("ras07*_vradh_*")

volume_reflectivity = np.array(
    sorted(volume_reflectivity, key=lambda x: x.split("-")[2])
)
volume_velocity = np.array(sorted(volume_velocity, key=lambda x: x.split("-")[2]))

volume_reflectivity = volume_reflectivity.reshape(-1, 10).T
volume_velocity = volume_velocity.reshape(-1, 10).T

Export to OdimH5#

This exports the radar volume at given timestep including all moments into one ODIM_H5 compliant data file.

xd.io.to_odim(vol0, "dwd_odim.h5", source="RAD:DWD")

Export to Cf/Radial2#

This exports the radar volume at given timestep including all moments into one Cf/Radial2 compliant data file.

xd.io.to_cfradial2(vol0, "dwd_cfradial2.nc")
